Tube and Tubeless Type

Tire School

Tube and Tubeless Type

How to choose tube or tubeless?
Tube Tire Tubeless Tire
Bias Tire Radial Tire 90 Series 80 Series 75 Series 70 Series 65 Series
7.00-16 7.00R16 8R17.5 / 205/75R17.5 / /
7.50-16 7.50R16 8.5R17.5 / 215/75R17.5 / /
8.25-16 8.25R16 9.5R17.5 / 235/75R17.5 245/70R19.5 /
7.50-20 7.50R20 8R22.5 / / / /
8.25-20 8.25R20 9R22.5 / / / /
9.00-20 9.00R20 10R22.5 / / 255/70R22.5 /
10.00-20 10.00R20 11R22.5 275/80R22.5 295/75R22.5 275/70R22.5 /
11.00-20 11.00R20 12R22.5 295/80R22.5 / / 385/65R22.5
12.00-20 12.00R20 13R22.5 315/80R22.5 / 315/70R22.5 425/65R22.5

 1. Tubeless Tire Features:

  • Outer diameter of a tubeless tire is the same as a tube tire, so the gear ratio will not change before or after a tire change
  • Rim diameter is 2 inches wider with better heat dissipation and lower temperatures
  • Load capacity remains the same with a lighter rim

  1. Advantages of Tubeless Tires: 10% Lighter Than Tube Tires
1. Lower sidewall for more accurate and safer steering and handling 2.Fewer components with lower friction and rolling resistance for better fuel efficiency 3.Superior heat dissipation and lower temperatures for longer tire life 4.Better contact area with uniform wear for longer tire life 5.Less components and lighter weight for reduced fuel consumption
