GITI GAR820 225/75R17.5 245/70R17.5

Features

GITI GAR820
  • New pattern design with wide solid shoulders
  • Optimized casing and footprint design
  • Specialized tread compound
  • Center block pattern design
  • New Improved bead construction

Specifications

GITI GAR820
Size PR Load Index Speed Rating Standard Rim Maximum Load (mm) Maximum Pressure (kPa) Tread Depth (mm) Outer Diameter (mm) Section Width (mm) TL/TT
kg lbs kPa psi
225/75R17.5 14 129/127 M 6.75 1850/1750 4080/3860 725/725 105/105 13.0 783 226 TL
245/70R17.5 14 136/134 M 7.50 2240/2120 4940/4675 850/850 123/123 13.5 789 248 TL
9.5R17.5 16 143/141 K 6.75 2725/2575 6005/5675 875/875 127/127 12.5 842 240 TL
235/75R17.5 16 132/129 J 6.75 2000/1850 4410/4079 830/830 120/120 13.5 797 233 TL
205/75R17.5 14 124/122 M 6.00 1600/1500 3530/3305 750/750 110/110 12.5 753 204 TL
215/75R17.5 14 128/126 M 6.00 1800/1700 3970/3750 750/750 110/110 13.0 767 211 TL
235/75R17.5 14 132/130 M 6.75 2000/1900 4410/4190 760/760 110/110 13.5 767 233 TL
