• Narrow Grooves: High resistance to wear and cutting for extra-heavy-duty mining performance
• Wide Shoulder Grooves: Provides traction in multiple mining conditions
• Proprietary Casing: Comprised of new compounds and a revolutionary steel cord with new anti-rust and adhesion coatings
| CATEGORY | SIZE | PLY /STAR RATING |
COMPOUND /CONSTRUCTION |
TRA /APPLICATION |
ARTICLE # | AVERAGE WEIGHT (LBS) |
OTD (32nd) |
OVERALL DIAMETER (IN) |
OVERALL WIDTH (IN) |
| GIANT TUBELESS | 46/90R57 | 2★ | E1A | E-4 | 429430 | 8450 | 122 | 140.7 | 45.4 |
| GIANT TUBELESS | 46/90R57 | 2★ | E2A | E-4 | 429447 | 8718 | 122 | 140.7 | 45.4 |
| GIANT TUBELESS | 46/90R57 | 2★ | E2A LS | E-4 | 429481 | 8718 | 122 | 140.7 | 45.4 |
| GIANT TUBELESS | 46/90R57 | 2★ | E3A | E-4 | 429464 | 8718 | 122 | 140.7 | 45.4 |
| SIZE | BRAND | MODEL | ADDITIONAL |
| 46/90R57 | Caterpillar | 793F | |
| 40.00R57; 46/90R57 | Belaz | 75310、75311、75312、75313、75315、75318、75319 | |
| 46/90R57 | Komatsu | 830E | |
| 46/90R57 | Hitachi | EH4000AC-3 | 40.00R57、50/80R57 |
| 46/90R57 | TEREX | MT4400AC | |
| 46/90R57 | XEMC | SF33900 |
