| Size | Ply | Service Index | Tread Depth (mm) | Standard Rim | Inflated Profile | Max. Load Capacity at Cold Inflation Pressure | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| Section Width | Overall Diameter | Single | Dual | |||||||
| (mm) | (mm) | (kg) | (kPa) | (kg) | (kPa) | |||||
| 5.00-12ULT | 10 | 88/86L | 9.0 | 3.50B | 143 | 568 | 560 | 500 | 530 | 500 |
| 5.50-13LT | 8+ | 88/84L | 10.0 | 4.00B | 160 | 620 | 565 | 420 | 500 | 420 |
| 6.00-13LT | 8+ | 93/89L | 10.0 | 4.50B | 170 | 655 | 650 | 420 | 580 | 420 |
| 6.00-14LT | 10 | 100/96L | 10.0 | 4 1/2J | 170 | 680 | 800 | 530 | 710 | 530 |
| 6.00-15LT | 10 | 101/97L | 11.0 | 4.50E | 170 | 705 | 825 | 530 | 730 | 530 |
| 6.50-15LT | 10 | 106/101L | 10.0 | 4.50E | 180 | 730 | 950 | 530 | 825 | 530 |
| 6.00-16LT | 10 | 102/98L | 10.0 | 4.50E | 170 | 730 | 860 | 530 | 750 | 530 |
*Reserves the rights of final interpretation and modification
