HILO BGZN 14.00R24 14.00R25 16.00R25 E2

Features

•Heat resistance compound and high speed durability.
•Providing reduced rubber tension for better resistance to cuts.
•Up to 10% additional tread volume.

Specifications

BGZN 14.00R24 14.00R25 16.00R25 HILO radial Crane tire

SIZE	STAR RATING	LOAD INDEX	TRA CODE	TREAD DEPTH	TYPE	Standard Rim (Rim Width &Flange)	DIAMETER	SECTION WIDTH	Max Load	STANDER PRESSURE	MAX SPEED
SIZE	STAR RATING	LOAD INDEX	TRA CODE	(mm)	TYPE	Standard Rim (Rim Width &Flange)	(mm)	(mm)	(kg)	(bar)	(Km/h)
14.00R24 ( 385/95R24)	★★★	170	E-2	23	TT	10.00W	1368	382	6000	10	70
14.00R25 ( 385/95R25)	★★★	170	E-2	23	TL	10.00/1.5	1368	382	6000	10	70
16.00R25 ( 445/95R25)	★★★	174/177	E-2	28	TL	11.25/2.0	1493	432	6700/7300	10	80/70

Description

BGZN 14.00R24 14.00R25 16.00R25 HILO Radial crane tire

Item	New Tire	HS Code	401180
Pattern Code	BGZN	Brand	Hilo
Cord Material	Steel Wire	Quality Warrantee	2 year
Tube Type	Tubeless	Delivery	Within 7 Days
Condition	New	Origin	Made in China
Natural Rubber	From Malaysia, Thailand, Indonesia etc	Certificate	DOT
Equipment	Imported From Japan and German	Manufactuer	Shandong Xingda Tire co., ltd
