| Size | PR | Load Index | Speed Rating | Standard Rim | Maximum Load (mm) | Maximum Pressure (kPa) | Tread Depth (mm) | Outer Diameter (mm) | Section Width (mm) | TL/TT | ||
| kg | lbs | kPa | psi | |||||||||
| 235/75R17.5 | 16 | 132/130 | M | 6.75 | 2000/1900 | 4410/4190 | 830/830 | 120/120 | 15.0 | 797 | 233 | TL |
| 225/70R19.5 | 14 | 128/126 | L | 6.75 | 1800/1700 | 3970/3750 | 760/760 | 110/110 | 14.3 | 817 | 226 | TL |
| 265/70R19.5 | 16 | 140/138 | M | 7.50 | 2500/2360 | 5510/5205 | 790/790 | 115/115 | 16.5 | 867 | 262 | TL |
| 225/75R17.5 | 14 | 129/127 | M | 6.75 | 1850/1750 | 4080/3860 | 725/725 | 105/105 | 15.0 | 783 | 226 | TL |
| 285/70R19.5 | 16 | 146/145 | M | 8.25 | 3000/2900 | 6610/6395 | 900/900 | 130/130 | 17.0 | 895 | 283 | TL |
| 245/70R19.5 | 16 | 136/134 | M | 7.50 | 2240/2120 | 4940/4675 | 830/830 | 120/120 | 16.0 | 839 | 248 | TL |
| 245/70R17.5 | 14 | 136/134 | M | 7.50 | 2240/2120 | 4940/4675 | 850/850 | 123/123 | 14.5 | 789 | 248 | TL |
| 205/75R17.5 | 14 | 124/122 | M | 6.00 | 1600/1500 | 3530/3305 | 750/750 | 110/110 | 14.0 | 753 | 204 | TL |
| 215/75R17.5 | 14 | 126/124 | M | 6.00 | 1700/1600 | 3750/3530 | 724/724 | 105/105 | 14.5 | 767 | 211 | TL |
| 9.5R17.5 | 18 | 143/141 | K | 6.75 | 2725/2575 | 6005/5675 | 875/875 | 127/127 | 12.5 | 842 | 211 | TL |
