HILO MWS L4 23.5R25 26.5R25 29.5R25 35/65R33 Tire Manufacturer and Distributor

Specifications

SIZE	STAR RATING	LOAD INDEX	TRA CODE	TREAD DEPTH	TYPE	Standard Rim (Rim Width &Flange)	DIAMETER	SECTION WIDTH	Max Load	STANDER PRESSURE	MAX SPEED
SIZE	STAR RATING	LOAD INDEX	TRA CODE	(mm)	TYPE	Standard Rim (Rim Width &Flange)	(mm)	(mm)	(kg)	(bar)	(Km/h)
23.5R25	★★	201	L-4	51	TL	19.50/2.5	1673	597	14500	6.5	10
26.5R25	★★	209	L4	60	TL	22.00/3.0	1798	673	18500	6.5	10
29.5R25	★★	216	L-4	67	TL	25.00/3.5	1921	750	22400	6.5	10
35/65R33	★★	224	L-4	62.5	TL	28.00/3.5	2065	889	28000	6.5	10

Description

Tire and Wheel Assembly

We receive the tires and wheels directly from the manufacturers and assemble them through several high quality and automated processes. We specialize in high precision tire-wheel assembly, logistics.

Advantages

There are many advantages of purchasing complete tire and wheel assemblies from us.
The assemblies are designed by experienced engineers, put together by a work force that manufactures tens of thousands per year, are subject to stringent quality control, and come with a warranty. Complete wheel and tire assemblies arrive at the customer inflated, with all mobility devices and accessories installed, ready to bolt onto the hub and drive away.

Save The Assembly Cost For Our Buyers
It's much cheaper to assemble them in China with our expertise.
Save The Freight Cost For Our Buyers
We ship more together than seperately.
Quality Warranty
All assemblies come with warranty.
Supply of Every Component
They come with accessories and ready to bolt on hubs.

Service Range

Proinde die funestis interrogationibus praestituto imaginarius iudex equitum resedit magister adhibitis aliis iam quae essent agenda praedoctis, et adsistebant hinc inde notarii, quid quaesitum esset, quidve responsum, cursim ad Caesarem perferentes.

Tubeless Tire, Tube Type Tire, Solid Tire, And Foam Filled Tires

Steel, Aluminum Wheels, And Galvanized Wheels

Range Of Tire/Rim Diameter From 4” To 54”, Wheel Barrow Tires To Off-Road Mining Tires

Manual Assembly

Our Service Steps

STEP 1
STEP 2
STEP 3
STEP 4
STEP 5

Step 1:
The fitter will get the new tires and wheels ready.
Step 2:
The diameter of the new tire should match the diameter of the rim, and it should be approved for use with the vehicle. Rims should be the correct size, in perfect condition, and free of rust. They must not be damaged, deformed, or worn.
Step 3:
Moving on to the tire beads, the fitter will coat the beads and the rim with fitting lubricant as recommended by the tire manufacturer. Then he will use the tire spreader to mount the tire onto the wheel.
Step 4:
Next comes the inflation of the tire. For the duration of this stage, the wheel must remain firmly secured on a mounting machine. Inflating an unsecured tire is dangerous. The fitter will be aware of this; it’s also why he keeps a reasonable distance from the tire during inflation. Typically, he will use a sufficiently long, secured extension hose with an integrated pressure gauge, and he won’t be bending over the tire as it fills up with air.
Step 5:
Once the beads of the tire are seated correctly on the shoulder of the rim, the fitter will increase the tire pressure to achieve a firm grip on the flanges of the rim. This fitting pressure shouldn’t exceed more than 150% of the maximum pressure recommended by the manufacturer. Next, the fitter will adjust the pressure to the operating pressure as specified by the vehicle manufacturer.

Automatic Assembly Line

Process of automatic assembly line consists of the following process steps:

Measuring Station
A
Wheel Soaping
Station
B
Tire and Wheel
Matching Station
E
Tire and Wheel Fitting (Mounting)
StationStation
D
Tire Soaping
Station
C
Inflation Station
F
Bead Optimizing
Station
G

Our Success Stories

Every year, we fit hundreds and thousands of tires to wheels.

Fitting Solid Tires

Fitting Agri. Tires

Fitting Highway Tires
Fitting OTR Tires

MWS HILO 23.5R25 26.5R25

Item	New Tire	HS Code	401180
Pattern Code	MWS	Brand	HILO
Cord Material	Steel Wire	Quality Warrantee	2 year
Tube Type	Tubeless	Delivery	Within 7 Days
Condition	New	Origin	Made in China
Natural Rubber	From Malaysia, Thailand, Indonesia etc	Certificate	DOT
Equipment	Imported From Japan and German	Market	Nigeria Ethiopia Egypt DR Congo Tanzania South Africa Kenya Uganda Sudan Algeria Morocco Angola Ghana Mozambique Madagascar Ivory Coast Cameroon Niger

HILO MWS L4 23.5R25 26.5R25 29.5R25 35/65R33

Features
