| Tyre Size | Ply Rating | Tyre Type | Tread Depth | Section Width | Overall Diameter | Max. Speed | Infl. Pressure | Max. Load | Standard Rim | ||||||
| (mm) | (32nds) | mm | inch | mm | inch | km/h | mph | kPa | psi | kg | lbs | ||||
| 26×12D380 | 8 | TL | 17.0 | 21.4 | 309 | 12.2 | 670 | 26.4 | 10 | 5 | 380 | 55 | 1550 | 3420 | 10.00 |
| 26×12.00-12 | 8 | TL | 19 | 23.9 | 309 | 12.2 | 670 | 26.4 | 10 | 5 | 350 | 51 | 1370 | 3020 | 10.50 |
| 31×15.5-15 | 8 | TL | 19 | 23.9 | 402 | 15.8 | 802 | 31.6 | 10 | 5 | 310 | 45 | 1980 | 4365 | 13.00 |
| 29×12.5-15 | 8 | TL | 21.5 | 27.1 | 325 | 12.8 | 770 | 30.3 | 10 | 5 | 320 | 46 | 1950 | 4300 | 10.00 |
Trencher Traction Master HF-3 Features:
* Best to meet the needs and demands of the most severe operational trencher machines
* Self-cleaning stepped tread lugs provide excellent traction
* Specially developed lugs offer smoothest ride available and increased stability
OTR is the short name for Off-the-Road.
OTR tire range usually refers to tires used on rough terrain low-speed applications.
