R4-AWP 385/65D22.5 (15-22.5)
Features
R4-AWP Features:
Self cleaning directional tread
Extra Heavy Duty sidewall and reinforced bead area
The flat profile allows for more surface contact and longer tread life
Increased stability in aerial lift
| Tire Size | PR | Pattern Code | Rim Size | Inflation Pressure (kpa) | Section Width（mm） | Overall Diameter （mm） | Max Load （kg）10km/h |
| 385/65D22.5 (15-22.5) | 16 | R4 | 22.5x11.75 | 690 | 390 | 1070 | 5590 |
| 445/65D22.5 (18-22.5) | 18 | R4 | 22.5x13 | 690 | 450 | 1150 | 7320 |
| 355/55D625 (14-24.5) | 14 | R4 | 24.5x11.75 | 520 | 350 | 940 | 3450 |
| 385/45-28 | 16 | R4 | 28x13 | 750 | 380 | 1070 | 6000 |
| 385/50D625 (15-625)A | 16 | R4 | 24.5x13 | 690 | 386 | 1010 | 5600 |
| 445/45D625(18-625)A | 16 | R4 | 24.5x15 | 690 | 430 | 1030 | 6900 |
| 385/50D625 (15-625)B | 16 | R4 | 24.5x13 | 690 | 386 | 960 | 5600 |
| 445/45D625(18-625)B | 16 | R4 | 24.5x15 | 690 | 430 | 960 | 6900 |
| 445/50D710 （18-710） | 18 | R4 | 28x15 | 590 | 445 | 1180 | 7320 |
| 315/55D20 | 12 | R4 | 20x11 | 550 | 318 | 848 | 2870 |
| 39x15-22.5 A | 16 | R4 | 22.5x13 | 690 | 375 | 970 | 6525 |
| 39x15-22.5 B | 16 | R4 | 22.5x13 | 690 | 360 | 940 | 6525 |
| 840x15.5-510 | 14 | R4 | 20x14 | 620 | 392 | 850 | 3670 |
| 240/55D17.5 | 12 | R4 | 17.5x6.75 | 690 | 220 | 715 | 2000 |
| Item | New Tire | HS Code | 401180 |
| Pattern Code | R4W | Brand | mainsailL/private labeling |
| Cord Material | Nylon | Quality Warrantee | 2 year |
| Tube Type | Tubeless | Delivery | Within 7 Days |
| Condition | New | Origin | Made in China |
| Natural Rubber | From Malaysia, Thailand, Indonesia etc | Certificate | DOT, ETRTO |
| Marekt | Singapore, North America, and the global | Manufactuer | Ameristar tires |
For more information on AWP tires, please visit: AWP TIRES
Major OE Manufactures：
JLG Lift Equipment | Lift and Equipment Manufacturer | US and Canada
Genielift Aerial Work Platforms | Genie (genielift.com)
Haulotte, Boom Lifts : Access Equipment (MEWP) – Haulotte North America (haulotte-usa.com)
SkyjacK Home | Skyjack
Snorkel | Snorkel (snorkellifts.com)
