R1-3 6.00-12 7.50-16

R1-3

The tire has good wear resistance and unique tread design, which greatly improves the service life

Good durability, Cut – Resistance, Excellent self-cleaning capability
Tractor Tyres

Get a Quote?

Specifications:

R1-3 Specification:

Tire Size	Ply Rating	Type		Tread Depth		Standard Rim	Available Rim	Inflated Dimensions				Load Capacity
Tire Size	Ply Rating	TT	TL	mm	inch	Standard Rim	Available Rim	Overall Width (mm)	Overall Width (inch)	Overall Diameter (mm)	Overall Diameter (inch)	Max Load kg	Inflation Kpa
6.00-12	6	TT		22.0	0.87	4.50E	5.00F	165	6.50	640	25.20	405	250
7.50-16	6	TT		25.0	0.98	5.00F	6LB	205	8.10	810	31.90	650	210
7.50-18	6	TT		14.0	0.55	5.50F	——	203	7.99	850	33.46	950	225
7.50-18	8	TT		14.0	0.55	5.50F	——	203	7.99	850	33.46	1135	270
7.50-20	6	TT		25.0	0.98	5.50F	5.00F	205	8.10	910	35.80	760	210
9.5-24	6	TT		30.0	1.18	W8	W8H、W7	241	9.50	1049	41.30	850	210
11-38	6	TT		32.0	1.26	W10	DW10	305	12.01	1540	60.63	1400	140
11-38	8	TT		32.0	1.26	W10	DW10	305	12.01	1540	60.63	1545	160
12.4-28	6	TT		34.0	1.34	W11	W10、W10H	315	12.40	1260	49.61	1275	170
12.4-28	8	TT		34.0	1.34	W11	W10、W10H	315	12.40	1260	49.61	1510	230
12.4-28	10	TT		34.0	1.34	W11	W10、W10H	315	12.40	1260	49.61	1700	280
12.4-28	12	TT		34.0	1.34	W11	W10、W10H	315	12.40	1260	49.61	1830	320
13.6-28	6	TT		37.0	1.46	W12	W11	345	13.58	1310	51.55	1430	160
13.6-28	8	TT		37.0	1.46	W12	W11	345	13.58	1310	51.55	1645	200
13.6-28	10	TT		37.0	1.46	W12	W11	345	13.58	1310	51.55	1910	250
13.6-28	12	TT		37.0	1.46	W12	W11	345	13.58	1310	51.55	2125	300
15-24	10	TT		38.0	1.50	W14	——	410	16.10	1330	52.40	2800	280
15.5-38	8	TT		36.0	1.42	W14L	DW14A	395	15.60	1570	61.80	2060	180
16.9-30	8	TT		39.5	1.56	W15L	W14L、DW14A	429	16.90	1486	58.50	2000	170
16.9-30	10	TT		39.5	1.56	W15L	W14L、DW14A	429	16.90	1486	58.50	2240	190
16.9-30	12	TT		39.5	1.56	W15L	W14L、DW14A	429	16.90	1486	58.50	2440	220
16.9-34	6	TT		36.0	1.42	W15L	DW14A	429	16.90	1585	62.40	1800	120
16.9-34	8	TT		36.0	1.42	W15L	DW14A	429	16.90	1585	62.40	2120	170
16.9-34	10	TT		36.0	1.42	W15L	DW14A	429	16.90	1585	62.40	2360	190
16.9-38	8	TT		43.0	1.69	W15L	DW14A	430	16.90	1685	66.30	2240	170
16.9-38	10	TT		43.0	1.69	W15L	DW14A	430	16.90	1685	66.30	2450	190
16.9-38	14	TT		43.0	1.69	W15L	DW14A	430	16.90	1685	66.30	2940	260
18.4-30	6	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1550	61.02	2120	110
18.4-30	8	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1550	61.02	2415	140
18.4-30	10	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1550	61.02	2815	180
18.4-30	12	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1550	61.02	3180	230
18.4-34	6	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1655	65.16	2250	110
18.4-34	8	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1655	65.16	2565	140
18.4-34	10	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1655	65.16	2990	180
18.4-34	12	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1655	65.16	3375	230
18.4-34	14	TT		37.0	1.46	W16L	W15L、DW16	467	18.39	1655	65.16	3630	260
18.4-38	6	TT		37.0	1.46	W16L	W15L	467	18.39	1755	69.09	2380	110
18.4-38	8	TT		37.0	1.46	W16L	W15L	467	18.39	1755	69.09	2715	140
18.4-38	10	TT		37.0	1.46	W16L	W15L	467	18.39	1755	69.09	3165	180
18.4-38	12	TT		37.0	1.46	W16L	W15L	467	18.39	1755	69.09	3575	230
18.4-38	14	TT		37.0	1.46	W16L	W15L	467	18.39	1755	69.09	3840	260
20.8-38	8	TT		50.5	2.00	W18A	18DD、DW18A	528	20.80	1834	72.20	2800	120
20.8-38	10	TT		50.5	2.00	W18A	18DD、DW18A	528	20.80	1834	72.20	3150	150
20.8-38	12	TT		50.5	2.00	W18A	18DD、DW18A	528	20.80	1834	72.20	3550	190
23.1-26	10	TT		54.0	2.13	DW20A	——	587	23.10	1603	63.10	2900	140
23.1-26	12	TT		54.0	2.13	DW20A	——	587	23.10	1603	63.10	3250	170
23.1-26	16	TT		54.0	2.13	DW20A	——	587	23.10	1603	63.10	3860	220

Description :

R1-3
