GITI GDR655 11R22.5 295/80R22.5
GITI GDR655
- Specially arranged block and sipe angle
- Four belt construction
- Widened tread width design
- Extended tread depth
- Giti specially-formulated tread compound
- Uniquely designed inter-dependant blocks at of tread pattern center
- FEA bead construction optimization concept for bead construction
Our company is located in Shanghai, China, and has business partners all over the world.We are committed to offering On-Road & Off-Road tires/wheels, which are applied to:
– Construction Machinery (Loaders, ADT, Skid-Steering machines & Graders)
– Transportation (Trucks, Buses & Trailers)
– Agricultural/Irrigation Equipment (Tractors, Combine Harvesters & Trailers)- Forestry Machines (Harvesters, Forwarders & Skidders)
– Material Handling (Reach stackers & Forklifts)
As a professional tire/wheel supplier, we not only know well about products, but also know how to identify the right tires for your equipment.”Quality products and quality service” is our permanent commitment to our customers. Based on the requirements of the International market, we just abstract and collect a summary of popular size tires for your selection. If you cannot find some sizes, patterns or varieties, please do not hesitate to contact us.
LET TNR BRING YOU MORE!
Specifications:
GITI GDR655 Specifications
Size | PR | Load Index | Speed Rating | Standard Rim | Maximum Load (mm) | Maximum Pressure (kPa) | Tread Depth (mm) | Outer Diameter (mm) | Section Width (mm) | TL/TT | ||
kg | lbs | kPa | psi | |||||||||
11R22.5 | 16 | 148/145 | M | 8.25 | 3150/2900 | 6940/6395 | 850/850 | 123/123 | 21.0 | 1050 | 279 | TL |
295/80R22.5 | 18 | 152/149 | M | 9.00 | 3550/3250 | 7830/7160 | 900/900 | 130/130 | 21.1 | 1044 | 298 | TL |
315/70R22.5 | 20 | 154/150 (152/148) | L(M) | 9.00 | 3750/3350 | 8270/7390 | 900/900 | 131/131 | 21.0 | 1014 | 312 | TL |
315/80R22.5 | 18 | 156/150 (154/150) | L(M) | 9.00 | 4000/3350 | 8820/7390 | 850/850 | 123/123 | 21.0 | 1076 | 312 | TL |
295/80R22.5 | 18 | 152/149 | M | 9.00 | 3550/3250 | 7830/7160 | 900/900 | 130/130 | 21.1 | 1044 | 298 | TL |
