High mileage compound:
Innovative raw material and high mileage compound ensure better wear performance and higher value.
Optimzed profile:
Good durability from reduced shearing stress between belts.Good even wear and high mileage from optimized footprint.
Good handling from innovative profile.”
Raw material :
Durability and robustness enhanced by high tensile cord and improved bead for better retreadability.
Goodversatility:
Optimized performance for various road conditions from unique rib design.
Even wear, high mileage:
“Good uneven wear resistance from optimized rigidity and width of the blocks.
High mileage from low void-to-fill ratio.”
Stone ejection:
The 3 zigzag grooves eject stones effectively and keep the tread robust.
12R22.5 AUSTONE AAH137 SPECIFICATION
| Size | PR | LI | SS | Measure Rim | Type | Max.Load (KG) |
Max Load (LBS) |
Max Inflation Pressure (kPa) |
Max Inflation Pressure (PSL) |
Dimension (mm) |
Tread Depth (mm) |
Tread Depth 32nds |
|||||
| Single | Dual | Single | Dual | Single | Dual | Single | Dual | Section width | O.D | ||||||||
| 12R22.5 | 18PR | 152/149 | L | 9 | TL | 3550 | 3250 | 7830 | 7160 | 930 | 930 | 135 | 135 | 300 | 1085 | 15 | 19 |
12R22.5 AAH137
| Item | New Tire | HS Code | 401120 |
| Pattern Code | AAH137 | Brand | AUSTONE |
| Cord Material | Steel Wire | Quality Warrantee | 120,000-150,000KM |
| Tube Type | Tubeless/ Tubeless | Delivery | Within 30 Days |
| Condition | New | Origin | Made in China |
| Natural Rubber | From Malaysia, Thailand, Indonesia etc | Certificate | DOT/ ECE/ GCC |
| Equipment | Imported From Japan and German | Market | Middle East, North America |
fitting to TBR
