·Extra-deep tread for severe cut and wear resistance.
·Extra heavy duty radial casing design.
·Reinforced all-steel radial casing.
| Pattern | Size | LI/SS | Star Rating | TRA Code or Application | Spec | TKPH | TMPH | OD | OW | SLR | SLW | OTD | Minimum dual spacing | Recommended Rim/Flange Height |
| VSMS | 9.00R20 | ** | L5S | D2A | - | - | 1054 | 260 | 474 | 303 | 51 | - | 7.00T | |
| 12.00R20 | ** | L5S | D2A | - | - | 1173 | 312 | 540 | 351 | 57 | - | 8.50V | ||
| 12.00R24 | ** | L5S | D2A | - | - | 1275 | 312 | 573 | 364 | 57 | - | 8.50V | ||
| 14.00R24 | ** | L5S | D2A | - | - | 1394 | 390 | 634 | 437 | 72 | - | 10.00W | ||
| 17.5R25 | */** | L5S | D2A | - | - | 1371 | 440 | 631 | 487 | 68.5 | - | 14.00/1.5 | ||
| 18.00R25 | */** | L5S | D2A | - | - | 1682 | 512 | 733 | 592 | 84.5 | - | 13.00/2.5 | ||
| 26.5R25 | ** | L5S | D2A | - | - | 1775 | 684 | 800 | 760 | 95 | - | 22.00/3.0 | ||
| 29.5R29 | ** | L5S | D2A | - | - | 2008 | 773 | 912 | 829 | 104.5 | - | 25.00/3.5 | ||
| 35/65R33 | ** | L5S | D2A | - | - | 2071 | 879 | 927 | 965 | 97 | - | 28.00/3.5 |
