BOTO BT212 11R22.5

Features

1. Mainly for long haul application of light truck and all position wheels on good road
2. For longitudinal grooves design exactly accords with quick movement feature of light truck
3. Low heating up compound ensures good wear resistance and fuel saving
4. Continuous pattern in shoulder avoids tire irregular wear

Specifications

11R22.5 BOTO BT212
SIZE PR NEW TYRE INFLATED DIMENSIONS(mm) LOAD INDEX MAX丄OAD (kg) PRESSURE SPEED RATING STANDARD RIM TREAD DEPTH (mm)
SECTION WIDTH OVERALL DIAMETER SINGLE/DUAL SINGLE/DUAL (kg) SINGLE/DUAL (kpa)
11R22.5 14PR 279 1054 144/142 2800/2650 720/720 M 8.25 14
11R22.5 14PR 279 1054 144/142 2800/2650 720/720 M 8.25 14
11R22.5 16PR 279 1054 146/143 3000/2725 830/830 M 8.25 14
11R22.5 16PR 279 1054 146/143 3000/2725 830/830 M 8.25 14
11R22.5 16PR 279 1054 146/143 3000/2725 830/830 L 8.25 14
11R24.5 14PR 279 1104 146/143 3000/2725 720/720 M 8.25 14
11R24.5 14PR 279 1104 146/143 3000/2725 720/720 M 8.25 14
11R24.5 16PR 279 1104 149/146 3250/3000 830/830 L 8.25 14
11R24.5 16PR 279 1104 149/146 3250/3000 830/830 L 8.25 14
12R22.5 18PR 300 1085 152/149 3550/3250 930/930 L 9 17.5
12R22.5 18PR 300 1085 152/149 3550/3250 930/930 L 9 17.5
255/70R22.5 14PR 255 930 136/133 2240/2060 700/700 M 7.5 14
255/70R22.5 16PR 255 930 140/137 2500/2300 800/800 M 7.5 14
255/70R22.5 16PR 255 930 140/137 2500/2300 830/830 M 7.5 14
255/70R22.5 16PR 255 930 140/137 2500/2300 830/830 M 7.5 14
285/75R24.5 14PR 283 1050 144/141 2800/2575 760/760 M 8.25 14
285/75R24.5 14PR 283 1050 144/141 2800/2575 760/760 M 8.25 14
285/75R24.5 16PR 283 1050 147/144 3075/2800 830/830 L 8.25 14
285/75R24.5 16PR 283 1050 147/144 3075/2800 830/830 L 8.25 14
295/75R22.5 14PR 298 1014 144/141 2800/2575 760/760 M 9 14
295/75R22.5 14PR 298 1014 144/141 2800/2575 760/760 M 9 14
295/75R22.5 16PR 298 1014 146/143 3000/2725 830/830 L 9 14
295/75R22.5 16PR 298 1014 146/143 3000/2725 830/830 L 9 14


Description

11R22.5  BT212

fitting to TBR
