ADVANCE E-4J 18.00-25 18.00-33

Features

Mine-dedicated formula and block deepened pattern design provide superior resistance to puncture, cutting and wear; high-performance nylon 66 frame material provides excellent resistance to impact and puncture and superior dimensional stability;
the design of wide and sturdy pattern and superior-strong carcass structure provides superior controllability stability;
the high-performance environmental-friendly formula combines with the high-performance nylon 66 frame material to provide excellent fatigue resistance, improve the tire's retread performance, and contribute to environmental protection.

Specifications

Pattern	Spec.	Ply rating	Tire type	Inflatable section width (mm)	Inflatable Outer Diameter (mm)	Speed rating	Inflation pressure (kPa)	Tire load (kg)	Measuring Rim	Valve	Pattern depth (mm)
E-4J	18.00-25	32	TT	500	1675	50	575	8750	13.00/2.5	DG09C	56.3
E-4J	18.00-25	36	TT	500	1675	50	625	9250	13.00/2.5	DG09C	56.3
E-4J	18.00-25	32	TL	500	1675	50	575	8750	13.00/2.5	TL	56.3
E-4J	18.00-33	32	TL	500	1875	50	575	10300	13.00/2.5	TL	55.1
E-4J	18.00-33	36	TL	500	1875	50	625	10600	13.00/2.5	TL	55.1
E-4J	21.00-33	32	TT	575	2000	50	500	10300	15.00/3.0	DG11C	59
E-4J	21.00-33	32	TL	575	2000	50	500	10300	15.00/3.0	TL	59
E-4J	21.00-35	36	TL	570	2050	50	550	12850	15.00/3.0	TL	55.9
E-4J	21.00-35	40	TL	570	2050	50	625	14000	15.00/3.0	TL	55.9
E-4J	24.00-35	42	TL	655	2175	50	550	16500	17.00/3.5	TL	62.7
E-4J	24.00-35	48	TL	655	2175	50	650	18500	17.00/3.5	TL	62.7
E-4J	27.00-49	48	TL	735	2700	50	575	25000	19.50/4.0	TL	65.2
E-4J	33.00-51	58	TL	895	3060	50	575	35500	24.00/5.0	TL	88.3
